Technical Data
Product Model | QFSF- | QFSD- | QFGF- | QFPT- |
Material | PVDF | PTFE | GF | PET |
Pore Size (μm) | 0.03-10.0 | 0.10-5.0 | 1.0-10.0 | 10-30 |
Oil Repellency Grade | AATCC118. 3 - 8 | |||
Reinforcement Material | Non(1), PP(3), PET(4) | |||
Thickness (μm) | 80 ~ 2000 |
Explanation:
1. Product implementation standard: QB/T01-2015 "PTFE microporous membrane"
QB/T05-2015 "Fluorine material microporous membrane - medical"
2. The X in the product model row indicates reinforement material
